File Structure
| Offset | Size | Description |
|---|---|---|
| 0x0 | 0x8 | magic "pfsSKKey" |
| 0x8 | 0x1 | major version (always 2) |
| 0x9 | 0x1 | minor version (always 0) |
| 0xA | 0x6 | 00 Filler |
| 0x10 | 0x10 | IV |
| 0x20 | 0x10 | Encrypted key |
| 0x30 | 0x20 | HMAC Value |
The first step is to check the HMAC of the file. The process is to use the HMAC key pfsSKKey__Secret from the Keys#PFS_Secret_Keys page to check the HMAC Value at position 0x30 in the file.
If it is correct, it proceeds to use the pfsSKKey__EncKey from the Keys#PFS_Secret_Keys to decrypt the Encrypted key at offset 0x20 using the IV at offset 0x10.
Usage
sealedkey data can be created using sceSblPostSsMgrEncryptSealedkeyForDriver
sealedkey data can be decrypted using sceSblPostSsMgrDecryptSealedkeyForDriver
main application of sealedkey is to store randomly generated secret which serves the same purpose as klicensee in PFS encryption.
sealedkey is created for savedata, trophies etc
